Plastic Liner M16 Circular Connector 4 PIN Male Female REACH For Military

Name: Plastic Liner M16 Circular Connector 4 PIN Male Female REACH For Military
Brand: Rigoal Connector
Price: 1 USD

Quality Plastic Liner M16 Circular Connector 4 PIN Male Female REACH For Military wholesale

Brand Name : Rigoal Connector

Model Number : M16

Certification : CE ， Rohs , IP68

Place of Origin : China

MOQ : 100

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000

Delivery Time : 30work day

Packaging Details : 46x30x30

Application : Automotive, Sensor or Automation

Product name : M16 assembly connector cable

Type : M16

Gender : female to male

Coupling nut/screw : Brass with nickel plated

Contacts : 2 3 4 5 6 7 8 12 14 16 19 24pins are available

Contact way : screw

Contact Now

Product Introduction
Product Name:
Waterproof IP67 4 8 core Connector Female Male M16 metal assembled plug
model number:M16-M04
series:M16 Connector
pin number:4pin 8pin
waterproof:IP67

Description
 Degree of protection IP67
 2 3 4 5 5A 6 7 8 12 14 16 19 24 poles are available
 Anti-vibration locking screw design
 RoHS & REACH Compliance
 The cable material have PVC or PUR,length according to customer demand

 Electrical Data
 Rated voltage:60V
 Insulation resistance:100MΩ
 Rated current::7A
 Contact resistance:≤5mΩ
 Ambient temperature:-25°C~+85°C

 Connector Specification
 Polarity:2pin 3pins, 4pins,5pins,6pins,8pins 12pin 14pin 16pin 19pin 24pin
 Overmold:Transparent TPU
 Contacts:Brass with gold plated
 Insert:TPU+GF
 Coupling nut/screw:Brass with nickel plated

Plastic Liner M16 Circular Connector 4 PIN Male Female REACH For Military
